Machining Center (BF-3060)

ROWE Bridge-Type 5-Axis Machining Center (BF-3060) ROWE Bridge-Type 5-Axis Machining Center, represented by model BF-3060, is crafted with European craftsmanship, using top-tier international components for exceptional stability, precision, and efficiency. Its high-rigidity gantry bridge structure, dual-drive gantry electronics, and modular design deliver strong dynamic performance and rigidity, ideal for high-speed 5-axis machining of 3D contours in light alloys, non-ferrous metals, and non-metals. The Z-axis adopts imported four-row ball linear guides with self-lubricating blocks, ensuring uniform force distribution and high mechanical precision, with a max adjustable stroke of 4m for large/thick materials. The X-axis features double-row wide linear guides for fast, stable operation. Key specs: X/Y/Z strokes of 6000/3000/2000mm (customizable up to 36000/10000/6000mm), A/B axis angles of +/-120°/+/-245°, 18.5KW spindle (7.5-55KW optional) with 24000r/min, and Siemens 840D system. Optional add-ons like linear scales and coolant systems meet diverse needs in rail transit, aerospace, and yacht industries.
